MODEL

UNIT

SDM-3228

SDM-4228

SDM-5228

TABLE

Overall Size

mm

3000×2500

4000×2500

5000×2500

Max. Loading

ton

12

14

18

TRAVEL

X Axis

mm

3200

4200

5200

Y Axis

mm

3300

Z Axis

mm

900

DISTANCE

Between Two Columns

mm

2800

Spindle Nose to Table Top

mm

270~1170

SPINDLE

Speed

rpm

4000 / 6000 (Driven by ZF Box)

Motor-cont / 30 min

kW

FANUC 15/18.5 (opt. 22/26)

Taper

BT/DIN/CAT-50 (opt. BT/DIN/CAT-40)

ATC

No. of ATC

tools

24 (opt. 32/40/60)

Max. Tool Length

mm

350

Max. Tool Weight

kg

18

MISCELLANCOUS

Power Required

kVA

50

CNC Controller

FANUC 0i-MF (opt. MITSUBISHI / SIEMENS / HEIDENHAIN)

●Standard Accessories

●Optional Accessories

Spindle Air Blast System

Spindle Oil Cooler

Automatic Lubrication System

M. P. G.

Heat Exchanger in Cabinet

Automatic Power off

Working Lamp & Alarm Lamp

Screw Auger、Chain type Chip Conveyor、Cart

Machine & Controller Manual

Levelling Bolts & Pads

Tool Box for Machine Adjustment

RS-232C / RJ-45 Terminal Interface

AICC II (200 block / 30m)

DATA SERVER + 2G CF Card

Splash Guard

Spindle Speed 8000 / 10000 / 12000 rpm

Spindle Motor Upgrade

Auxiliary Table

4th Axis Rotary Table

Air Conditioner in Cabinet

Milling Head

ATC with 32/40/60 Tools Magazine

Coolant Through Spindle (C.T.S.)

Linear Scale for Three Axes

Auto. Tool Setter Renishaw (TS-27R)

Auto. Workpiece Measurement (OMP-60 / RMP-60)

Cutting Coolant Mist Device

Full Splash Guard with Top Cover

Heat Compensation

CNC Controller (MITSUBISHI / SIEMENS / HEIDENHAIN)

Specifications are subject to change without notice
